Main Input Voltage | 230 V |
|---|---|
Main Output Voltage | 230 V |
Rated power in W | 300 W |
Rated power in VA | 500 VA |
Input Connection Type | NEMA 5-15P |
output connection type | 4 universal receptacle |
Cable length | 1.52 m |
Number of cables | 1 |
Battery type | Lead-acid battery |
Provided equipment | User manual |
ประสิทธิภาพ | |
|---|---|
Number of battery filled slots | 0 |
Number of battery free slots | 0 |
Battery recharge time | 8 h |
Extended runtime | 0 |
Number of power module free slots | 0 |
|---|---|
Number of power module filled slots | 0 |
Redundant | No |
UPS size | WS |
Colour | Black |
|---|---|
height | 9.2 cm |
Width | 16.1 cm |
Depth | 30.5 cm |
Net weight | 3.9 kg |
Mounting preference | No preference |
Mounting mode | Not rack-mountable |
Two post mountable | 0 |
USB compatible | No |
Network frequency | 50/60 Hz +/- 5 Hz auto-sensing |
|---|---|
Input voltage limits | 170...280 V |
Maximum configurable power in W | 300 W |
|---|---|
Output frequency | 50/60 Hz +/- 1 Hz unsynchronised |
UPS type | Line interactive |
Wave type | Stepped approximation to a sinewave |
Graph display | 1 |
Maximum configurable power in VA | 500 VA |
Transfer time | 6 ms typical : 10 ms maximum |
product certifications | CE TISI |
|---|---|
Standards | EN/IEC 62040-1:2019/A11:2021 EN/IEC 62040-2:2006/AC:2006 EN/IEC 62040-2:2018 |
Ambient air temperature for operation | 0…40 °C |
|---|---|
Relative humidity | 0…90 % |
Operating altitude | 0...6561 ft |
Ambient air temperature for storage | -20…50 °C |
Storage Relative Humidity | 0…90 % |
Storage altitude | 0.00…15240.00 m |
Acoustic level | 40 dBA |
IP degree of protection | IP20 |
Alarm | Alarm when on battery : distinctive low battery alarm : overload continuous tone alarm |
|---|
Surge energy rate | 156 J |
|---|
Unit Type of Package 1 | PCE |
|---|---|
Number of Units in Package 1 | 1 |
Package 1 Height | 23.7 cm |
Package 1 Width | 37.3 cm |
Package 1 Length | 14.3 cm |
Package 1 Weight | 4.2 kg |
SCC14 | 10731304346835 |
รับประกันศูนย์ไทย 2 ปี
