Main Input Voltage | 230 V |
|---|---|
Other Input Voltage | 220 V 240 V |
Main Output Voltage | 230 V |
Other Output Voltage | 220 V 240 V |
Rated power in W | 1000 W |
Rated power in VA | 1500 VA |
Input Connection Type | IEC 320 C14 |
output connection type | 8 IEC 320 C13 2 IEC Jumpers |
Cable length | 1.83 m |
Number of cables | 1 |
Battery type | Lead-acid battery |
Provided equipment | Installation guide USB cable |
Software package | SmartConnect software for remote power monitoring feature availability varies by terms of use |
|---|
รันไทม์ | |
|---|---|
ประสิทธิภาพ | |
Additional information | Configurable for 220 : 230 or 240 nominal output voltage |
Extended runtime | 0 |
Number of battery filled slots | 0 |
Number of battery free slots | 0 |
Battery recharge time | 3 h |
Number of battery replacement quantity | 1 |
Battery life | 3…5 year(s) |
Replacement battery | |
Battery charger power | 136 W rated |
Number of power module filled slots | 0 |
|---|---|
Number of power module free slots | 0 |
product web sub-family | Cloud-enabled monitoring |
Redundant | No |
Colour | Black |
|---|---|
height | 21.9 cm |
Width | 17.1 cm |
Depth | 43.9 cm |
Net weight | 24.09 kg |
Mounting location | Front |
Mounting preference | No preference |
Mounting mode | Not rack-mountable |
Two post mountable | 0 |
USB compatible | No |
Input voltage limits | 151...302 V adjustable 160...286 V |
|---|---|
Network frequency | 50/60 Hz +/- 3 Hz auto-sensing |
Harmonic distortion | Less than 5 % |
|---|---|
Maximum configurable power in VA | 1500 VA |
Maximum configurable power in W | 1000 W |
Transfer time | 6 ms typical : 10 ms maximum |
UPS type | Line interactive |
Wave type | Sine wave |
Output frequency | 50/60 Hz +/- 3 Hz sync to mains |
product certifications | CE EAC RCM VDE |
|---|---|
Standards | EN/IEC 62040-1:2019/A11:2021 EN/IEC 62040-2:2006/AC:2006 EN/IEC 62040-2:2018 |
Acoustic level | 45 dBA |
|---|---|
heat dissipation | 135 Btu/h |
Operating altitude | 0...10000 ft |
Ambient air temperature for operation | 0…40 °C |
Ambient air temperature for storage | -15…45 °C |
Storage altitude | 0.00…15240.00 m |
Relative humidity | 0…95 % |
Storage Relative Humidity | 0…95 % |
control panel | Multifunction LCD status and control console |
|---|---|
Free slots | 1 |
Communication port support | SmartConnect Ethernet port: for cloud monitoring feature availability varies by terms of use |
Alarm | Alarm when on battery : distinctive low battery alarm : overload continuous tone alarm |
Surge energy rate | 459 J |
|---|---|
Noise suppression | Full time multi-pole noise filtering : 0.3% IEEE surge let-through : zero clamping response time : meets UL 1449 |
Unit Type of Package 1 | PCE |
|---|---|
Number of Units in Package 1 | 1 |
Package 1 Height | 37.6 cm |
Package 1 Width | 59.5 cm |
Package 1 Length | 32.8 cm |
Package 1 Weight | 27.23 kg |
